Play with OpenStack instance metadata

Nova API metadata.

I. Reminder

First check the OpenStack official documentation about the metadata service. Metadata Ideally if you run an OpenStack production environment you will opt for a multi compute node solution which requires nova metadata service on each nova-compute node (for performance purpose). You can assign the metadata server like so:

  1. Use the metadata_host option in nova.conf, specify the IP address of the node running nova-api
  2. Run the nova-api service on each nova-compute node and specify the enabled_apis = metadata flag in nova.conf
  3. Or the last option (my favorite), simply run the nova-api-metadata (with the same name package) service on each nova-compute node. It doesn’t require any modification in nova.conf (default options are enough)

Flags related to metadata in nova.conf:

  • metadata_listen_port = 8775
  • metadata_host = 172.17.1.3
  • metadata_manager = nova.api.manager.MetadataManager
  • quota_metadata_items = 128
  • metadata_listen = 0.0.0.0
  • enabled_apis = [‘ec2’, ‘osapi_compute’, ‘osapi_volume’, ‘metadata’]
  • metadata_port = 8775

The cloud-init service hosted inside each cloud-image retrieves the metadata during the boot sequence. Metadata contains a lot of information related to the running instance. For example ssh keys will be injected in order to access the virtual instance (always during the boot sequence).

II. Play!

First pick up an instance and ssh into it. You’r ready to retrieve the metadata, you can use both wget or curl. I have a preference for curl because it shows the content and doesn’t download it immediately:

$ curl http://169.254.169.254/latest/meta-data/
reservation-id
public-keys/
security-groups
public-ipv4
ami-manifest-path
instance-type
instance-id
local-ipv4
local-hostname
placement/
ami-launch-index
public-hostname
hostname
ami-id
instance-action

Try to download the ssh public key:

$ curl http://169.254.169.254/latest/meta-data/public-keys//0/openssh-key -O
  % Total    % Received % Xferd  Average Speed   Time    Time     Time  Current
                                 Dload  Upload   Total   Spent    Left  Speed
100   228  100   228    0     0   1763      0 --:--:-- --:--:-- --:--:--  1767

$ cat openssh-key
ssh-rsa AAAAB3NzaC1yc2EAAAADAQABAAAAgQCwtA1rJf0JPZKfpUPBkW/b30bVJ/ZgzSJsjwFWFDjJIxkxlUPWkan8k6mZs7gedLC+5edi4voNFU3Yg/G73GP9M+m1aV51feK5NShNux6kY49/iAHvxwPnbpN2SpAJs+9r0aeKCTwfefSExKLFrdmkjtZOn+bvp5kFEMK43X2sqQ== nova@server-05

That’s all!
