Ceph cli output analysis

Brief analysis of the ceph -s command :)

I. Ceph in action!

If you are running a Ceph cluster you are certainly aware of the ceph -s command, which provides useful information about the state of your Ceph cluster. Let’s describe his output line by line:

$ ceph -s
   health HEALTH_OK
   monmap e1: 3 mons at {0=172.17.1.4:6789/0,1=172.17.1.5:6789/0,2=172.17.1.7:6789/0}, election epoch 44, quorum 0,1,2 0,1,2
   osdmap e455: 3 osds: 3 up, 3 in
   pgmap v498444: 592 pgs: 592 active+clean; 33513 MB data, 54010 MB used, 136 GB / 199 GB avail
   mdsmap e39: 0/0/1 up

I.1. Health

Health state:

health HEALTH_OK

Several state are available with this format: HEALTH_WARN MESSAGE. As I can remember you can get these messages:

  • osds are down
  • nearfull osds
  • full osds

Come with these message the state of the PGs, the PGs stale.

I.2. monmap

Monitors

monmap e1: 3 mons at {0=172.17.1.4:6789/0,1=172.17.1.5:6789/0,2=172.17.1.7:6789/0}, election epoch 44, quorum 0,1,2 0,1,2

Line description:

  • Number of monitor
  • IP address of every monitors and listenned port
  • The map version: epoch
  • Quorum status

For further information about the quorum you can use the following command:

$ ceph quorum_status
{ "election_epoch": 22,
  "quorum": [
        0,
        1,
        2],
  "monmap": { "epoch": 1,
      "fsid": "d1b8d687-0d00-40d5-aa14-8734fc1e4c58",
      "modified": "2012-08-08 18:04:24.572191",
      "created": "2012-08-08 18:04:24.572191",
      "mons": [
            { "rank": 0,
              "name": "1",
              "addr": "172.17.1.6:6789\/0"},
            { "rank": 1,
              "name": "2",
              "addr": "172.17.1.7:6789\/0"},
            { "rank": 2,
              "name": "0",
              "addr": "172.17.1.12:6789\/0"}]}}

I.3. osdmap

OSDs map

osdmap e455: 3 osds: 3 up, 3 in

Line description:

  • Version of the map
  • Number of OSDs
  • OSDs status:
    • up: online and reacheable
    • in: devices are included in the crush map

I.4. pgmap

Placement group map:

pgmap v498444: 592 pgs: 592 active+clean;

Line description:

  • pgmap: placement group map
  • v498444: map version
  • 592 pgs: number of placement group
  • active+clean: state of these pgs.
    • active: retrievable
    • clean: number of replica is ok

End of the line, data description:

  • 33513 MB data: raw data stored
  • 54010 MB used: real used space, take a replica size into account. Roughly if you see 20G in data, you should see a little bit less than 40G in used. The used description is more or less (datax replica_count) - journals_size_combined.
  • 136 GB / 199 GB avail: (total_raw_space) - (used space)

I.5. mdsmap

Metadata server’s map

mdsmap e39: 0/0/1 up

This output isn’t really surpising since I don’t run any MDS daemon. This line describe:

  • Version of the mdsmap
  • Number of MDS server up


Hope this little analysis will help your understanding of the ceph output
