How to use a memory profiler to track memory usage of Ceph daemons!

To start tracking right away during daemon’ startup simply put the following variable in the /etc/init.d/ceph script and start your OSD daemon:

export CEPH_HEAP_PROFILER_INIT=1

The position doesn’t really matter ;-).

$ sudo service ceph start osd.0
=== osd.0 ===
Starting Ceph osd.0 on ceph-01...
Starting tracking the heap
starting osd.0 at :/0 osd_data /srv/ceph/osd0 /journal/journal

Start the profiler:

$ ceph osd tell 0 heap start_profiler
ok

Ceph log shows:

osd.0 [INF] osd.0 started profiler

Let the profiler running and after some hours, dump the results into a file:

$ ceph osd tell 0 heap dump
ok

Ceph log shows:

osd.0 [INF] osd.0dumping heap profile now.
osd.0 [INF] ------------------------------------------------
osd.0 [INF] MALLOC:       10810792 (   10.3 MB) Bytes in use by application
osd.0 [INF] MALLOC: +       438272 (    0.4 MB) Bytes in page heap freelist
osd.0 [INF] MALLOC: +       172656 (    0.2 MB) Bytes in central cache freelist
osd.0 [INF] MALLOC: +       165632 (    0.2 MB) Bytes in transfer cache freelist
osd.0 [INF] MALLOC: +      2044136 (    1.9 MB) Bytes in thread cache freelists
osd.0 [INF] MALLOC: +       786432 (    0.8 MB) Bytes in malloc metadata
osd.0 [INF] MALLOC:   ------------
osd.0 [INF] MALLOC: =     14417920 (   13.8 MB) Actual memory used (physical + swap)
osd.0 [INF] MALLOC: +            0 (    0.0 MB) Bytes released to OS (aka unmapped)
osd.0 [INF] MALLOC:   ------------
osd.0 [INF] MALLOC: =     14417920 (   13.8 MB) Virtual address space used
osd.0 [INF] MALLOC:
osd.0 [INF] MALLOC:           2669              Spans in use
osd.0 [INF] MALLOC:             36              Thread heaps in use
osd.0 [INF] MALLOC:           4096              Tcmalloc page size
osd.0 [INF] ------------------------------------------------
osd.0 [INF] Call ReleaseFreeMemory() to release freelist memory to the OS (via madvise()).
osd.0 [INF] Bytes released to the OS take

Stop the profiler:

$ ceph osd tell 0 heap stop_profiler
ok

Log shows:

osd.0 [INF] osd.0 stopped profiler

Read the .heap file with Google heap tool:

$ sudo apt-get install google-perftools -y
$ sudo google-pprof /usr/bin/ceph-osd -gv osd-0001.heap

Hint, if you don’t have any virtual interface you can look for a text content:

$ sudo google-pprof /usr/bin/ceph-osd --text osd-0001.heap

I had to use a memory profiler because I recently noticed some memory leaks from Ceph OSDs. This has been discussed on the Ceph Mailing List.
